Huizhou PengQiang, service-oriented, provide one-stop service, Ships within Five business days.
Laser chillers are often used to cool UV lasers, CO2 laser glass tubes, semiconductor lasers, CO2 RF tube lasers, and fiber lasers for cutting machines, marking machines, engraving machines, and other equipment. Users can choose suitable chillers according to different laser powers.
| Model | Product name | PQ-ZL01L |
| Power | Voltage | 1N/220V/50hz |
| Power Supply(KW) | 1.21 | |
| Cooling Capacity | Kcal/H | 2107 |
| KW | 2.45 | |
| Temperature Range | ℃ | 5℃~30℃（± 0.3 ℃ Could be customized） |
| Refrigerant | Name | R22(Or R134a/R407c) |
| Control Method | Capillary Tube | |
| Compressor | Type | Hermetic Scroll Type or Piston Compressor |
| Brand | GREE | |
| Power(KW) | 0.75*1 | |
| Draught Fans | Power（KW） | 0.09 |
| Condenser | Form | Efficient Brass Sets Coorrugated Aluminum Fin |
| Evaporate | Water Tank Volume(L) | 16 |
| Inlet/Outlet (DN) | 1/2″ | |
| Water Pump | Water Flow(L/MIN) | 33 |
| Power(KW) | 0.37 | |
| Convey Water（M） | 24~30 | |
| Brand | Auyuan | |
| Whole Machine | Net Weight（KG） | 56 |
| Dimension（CM） | 41.3*40*87.1 |
Cooling capacity up to 2107 Kcal/H.
Brand compressor, low consumption, quite, efficient refrigeration
High convey copper wire stainless steel water pump,long service life, clean water.
Large air volume fan.
Using the original GREE compressor, energy saving running sound like whispering.
High-end microcomputer operation and temperature control.
High capacity capacitor.
The built-in protection program of the computer board reduces the failure and damage to the chiller caused by wrong operation.
External rotor fan with strong wind and rapid heat dissipation.
