5HP air cooled chiller delivers 14 kW (12,500 kcal/h) cooling capacity with a stable temperature range of 5°C–35°C (sub-zero customization available) and equipped with a high-performance Panasonic compressor, efficient heat exchange system, and built-in water tank & pump. The 5hp chiller ensures reliable, energy-efficient operation across industries such as chemical processing, food production, electronics, film blowing, reflow soldering, precision machinery, laboratories, and pharmaceuticals.
Both standard models and fully customized solutions are available to meet specific project requirements. Backed by PengQiang’s service-oriented approach, we provide one-stop support with fast production and delivery—ready to ship within 5 business days.
| Model | Product name | PQ-ZL05A |
| Power | Voltage | 3N/380V/50HZ/50hz |
| Cooling Capacity | Kcal/H | 12500 |
| KW | 14 | |
| Temperature Range | ℃ | 5℃~35℃（Below 0℃ Could be customized） |
| Refrigerant | Name | R22(Or R134a/R407c) |
| Control Method | Capillary Tube | |
| Compressor | Type | Hermetic Scroll Type or Piston Compressor |
| Brand | Panasonic | |
| Power(KW) | 3.75 | |
| Draught Fans | Air Volume（M³/H) | 7000 |
| Power（KW） | 0.38*2 | |
| Dimension Fans（MM） | 400*2 | |
| Heat Dissipation Ambient Temperature | ≤35℃ | |
| Condenser | Form | Efficient Brass Sets Coorrugated Aluminum Fin |
| Evaporate | Water Volume(M³/H) | 2.4 |
| Water Tank Volume(L) | 60 | |
| Inlet/Outlet (DN) | 25 | |
| Circulating Pump | Water Flow | 100(L/min) |
| Power(KW) | 0.37 | |
| Convey Water（M） | 18 | |
| Brand | Auyuan | |
| Whole Machine | Weight（KG） | 190 |
| Dimension（CM） | 130*65*130 |
Air cooled 5HP portable & packaged chiller.
Water tank capacity upgraded to 100L.
Easy intallation, connected with pipe and power on is ok for working.
No need to purchase a water tower.
Comes with cooling.
The air cooled chiller can be used alone, and it works best when installed in a ventilated and dust-free environment.
High-quality iron outer box to prevent collision damage.
The fully enclosed scroll compressor is adopted, and the compressor will automatically stop running when the set temperature is reached, with high efficiency ratio, energy saving and power saving, and stable operation.
safe for user.
Provide customized services.
